Audio
Misc
1x PS/2
Network
1x RJ-45
USB
Video
Audio
1x SPDIF Out Header
Fans
5x 4-pin Fan Header
Misc
Power
Storage
6x SATA3
USB
PCB Color
Black
Other Colors
LED Color
RGB
| Amount | Chip | Speed | For IPMI |
|---|---|---|---|
| 1x | Realtek [Unknown] | 1000 Mbit | No |
| Audiochip | Realtek ALC1220 |
|---|---|
| Audio Channels | 7.1 |
Crossfire & SLI
| AMD Crossfire | Yes |
| Nvidia SLI | No |
Slots
M.2 Connections
| Amount | Slot | Sizes | Speeds |
|---|---|---|---|
| 1x | M-Key | 22110, 2242, 2260, 2280, | PCI-E 3.0 x4, SATA3, |
This board has 4 slots with the following specifications:
| Slot Protocol | DDR4 |
|---|---|
| Slot Type | 288-pin DIMM |
| Maximum Speed | 3200 MHz |
| Maximum Capacity | 64 GB |
| Maximum Channels | 2 |
| ECC support | No |
